How to Perform Comprehensive Cost Analysis—Including Compute

How to Perform Comprehensive Cost Analysis—Including Compute, Storage, Bandwidth, Energy, and SLA Penalties—in a Simulated Cloud Environment?

Host-Level Power Consumption Using Planetlab

Condition for Perform Comprehensive Cost Analysis—Including Compute, Storage, Bandwidth, Energy, and SLA Penalties—in a Simulated Cloud Environment

Description:
It simulates a container-based cloud data center using CloudSim and evaluates the power consumption of physical hosts under different resource allocation strategies. It creates multiple hosts, virtual machines, containers, and cloudlets, and schedules their execution using power-aware VM allocation and migration policies. The simulation collects metrics such as host-level power usage, total energy consumption, and cloudlet execution details to analyze the impact of overbooking and workload consolidation on energy efficiency. By modeling realistic workloads and monitoring the energy drawn by each host, this program helps researchers understand how container placement and VM migration strategies influence overall power consumption in cloud infrastructures.

Sample Code

package containercloudsim;

import java.io.FileNotFoundException;
import java.text.DecimalFormat;
import java.util.ArrayList;
import java.util.Calendar;
import java.util.LinkedList;
import java.util.List;
import org.cloudbus.cloudsim.Cloudlet;
import org.cloudbus.cloudsim.Log;
import org.cloudbus.cloudsim.Storage;
import org.cloudbus.cloudsim.UtilizationModelNull;
import org.cloudbus.cloudsim.container.containerProvisioners.ContainerBwProvisionerSimple;
import org.cloudbus.cloudsim.container.containerProvisioners.ContainerPe;
import org.cloudbus.cloudsim.container.containerProvisioners.ContainerPeProvisionerSimple;
import org.cloudbus.cloudsim.container.containerProvisioners.ContainerRamProvisionerSimple;
import org.cloudbus.cloudsim.container.containerVmProvisioners.ContainerVmBwProvisionerSimple;
import org.cloudbus.cloudsim.container.containerVmProvisioners.ContainerVmPe;
import org.cloudbus.cloudsim.container.containerVmProvisioners.ContainerVmPeProvisionerSimple;
import org.cloudbus.cloudsim.container.containerVmProvisioners.ContainerVmRamProvisionerSimple;
import org.cloudbus.cloudsim.container.core.Container;
import org.cloudbus.cloudsim.container.core.ContainerCloudlet;
import org.cloudbus.cloudsim.container.core.ContainerDatacenter;
import org.cloudbus.cloudsim.container.core.ContainerDatacenterBroker;
import org.cloudbus.cloudsim.container.core.ContainerDatacenterCharacteristics;
import org.cloudbus.cloudsim.container.core.ContainerHost;
import org.cloudbus.cloudsim.container.core.ContainerVm;
import org.cloudbus.cloudsim.container.core.PowerContainer;
import org.cloudbus.cloudsim.container.core.PowerContainerDatacenter;
import org.cloudbus.cloudsim.container.core.PowerContainerDatacenterCM;
import org.cloudbus.cloudsim.container.core.PowerContainerHost;
import org.cloudbus.cloudsim.container.core.PowerContainerHostUtilizationHistory;
import org.cloudbus.cloudsim.container.core.PowerContainerVm;
import org.cloudbus.cloudsim.container.hostSelectionPolicies.HostSelectionPolicy;
import org.cloudbus.cloudsim.container.hostSelectionPolicies.HostSelectionPolicyFirstFit;
import org.cloudbus.cloudsim.container.resourceAllocatorMigrationEnabled
.PowerContainerVmAllocationPolicyMigrationAbstractHostSelection;
import org.cloudbus.cloudsim.container.resourceAllocators.ContainerAllocationPolicy;
import org.cloudbus.cloudsim.container.resourceAllocators.ContainerVmAllocationPolicy;
import org.cloudbus.cloudsim.container.resourceAllocators.PowerContainerAllocationPolicySimple;
import org.cloudbus.cloudsim.container.schedulers.ContainerCloudletSchedulerDynamicWorkload;
import org.cloudbus.cloudsim.container.schedulers.ContainerSchedulerTimeSharedOverSubscription;
import org.cloudbus.cloudsim.container.schedulers.ContainerVmSchedulerTimeSharedOverSubscription;
import org.cloudbus.cloudsim.container.utils.IDs;
import org.cloudbus.cloudsim.container.vmSelectionPolicies.PowerContainerVmSelectionPolicy;
import org.cloudbus.cloudsim.container.vmSelectionPolicies
.PowerContainerVmSelectionPolicyMaximumUsage;
import org.cloudbus.cloudsim.core.CloudSim;
import org.cloudbus.cloudsim.examples.container.ConstantsExamples;
import org.cloudbus.cloudsim.examples.container.UtilizationModelPlanetLabInMemoryExtended;

public class ResourceCostEvaluation {

private static List vmList;
private static List containerList;
private static List cloudletList;
private static List hostList;
private static ContainerDatacenter datacenter;
private static ContainerDatacenterBroker broker;

// Metrics collection
private static double totalCost = 0.0;
private static double totalEnergy = 0.0;
private static double makespan = 0.0;
private static double totalResponseTime = 0.0;
private static double totalLatency = 0.0;
private static double totalBandwidth = 0.0;
private static int slaViolations = 0;
private static int completedCloudlets = 0;

public static void main(String[] args) {
Log.printLine("Starting ContainerCloudSim Exercise...");

try {
// First step: Initialize the CloudSim package
int numUsers = 1;
Calendar calendar = Calendar.getInstance();
boolean traceFlag = false;

CloudSim.init(numUsers, calendar, traceFlag);

// Second step: Create Datacenter
ContainerAllocationPolicy containerAllocationPolicy = new PowerContainerAllocationPolicySimple();
PowerContainerVmSelectionPolicy vmSelectionPolicy = new PowerContainerVmSelectionPolicyMaximumUsage();
HostSelectionPolicy hostSelectionPolicy = new HostSelectionPolicyFirstFit();
double overUtilizationThreshold = 0.80;
double underUtilizationThreshold = 0.70;

// Create host list
hostList = createHostList(5); // 5 hosts

// Create VM allocation policy
ContainerVmAllocationPolicy vmAllocationPolicy = new PowerContainerVmAllocationPolicyMigrationAbstractHostSelection(
hostList, vmSelectionPolicy, hostSelectionPolicy,
overUtilizationThreshold, underUtilizationThreshold);

// Third step: Create Broker with overbooking factor
int overBookingFactor = 80;
broker = createBroker(overBookingFactor);
int brokerId = broker.getId();

// Fourth step: Create VMs, Containers and Cloudlets
vmList = createVmList(brokerId, 10); // 10 VMs
containerList = createContainerList(brokerId, 20); // 20 containers
cloudletList = createContainerCloudletList(brokerId, 20); // 20 cloudlets

// Create datacenter
String experimentName = getExperimentName("ContainerCloudSimExercise", String.valueOf(overBookingFactor));
String logAddress = "~/Results";

datacenter = (PowerContainerDatacenter) createDatacenter(
"Datacenter_1", PowerContainerDatacenterCM.class,
hostList, vmAllocationPolicy, containerAllocationPolicy,
experimentName, ConstantsExamples.SCHEDULING_INTERVAL,
logAddress, ConstantsExamples.VM_STARTTUP_DELAY,
ConstantsExamples.CONTAINER_STARTTUP_DELAY);

// Submit VMs, containers and cloudlets to the broker
broker.submitVmList(vmList);
broker.submitContainerList(containerList);
broker.submitCloudletList(cloudletList);

// Fifth step: Starts the simulation
CloudSim.terminateSimulation(86400.00); // 24 hours simulation
CloudSim.startSimulation();

// Final step: Print results when simulation is over
List newList = broker.getCloudletReceivedList();
CloudSim.stopSimulation();

// Calculate all metrics
calculateMetrics(newList);

// Print comprehensive results
printCloudletList(newList);
printComprehensiveMetrics();

Log.printLine("ContainerCloudSim Exercise finished!");
} catch (Exception e) {
e.printStackTrace();
Log.printLine("The simulation has been terminated due to an unexpected error");
}
}

private static void calculateMetrics(List cloudletList) {
completedCloudlets = 0;
totalResponseTime = 0.0;
totalLatency = 0.0;
makespan = 0.0;
slaViolations = 0;

// SLA parameters
final double MAX_RESPONSE_TIME_SLA = 1000.0; // 1000 seconds max response time
final double MAX_LATENCY_SLA = 50.0; // 50 seconds max latency

for (ContainerCloudlet cloudlet : cloudletList) {
if (cloudlet.getCloudletStatus() == Cloudlet.SUCCESS) {
completedCloudlets++;

// Calculate response time (submission to start execution)
double responseTime = cloudlet.getFinishTime() - cloudlet.getExecStartTime();
totalResponseTime += responseTime;

// Calculate latency (approximated as response time for this simulation)
double latency = responseTime;
totalLatency += latency;

// Calculate makespan (maximum finish time)
if (cloudlet.getFinishTime() > makespan) {
makespan = cloudlet.getFinishTime();
}

// Check SLA violations
if (responseTime > MAX_RESPONSE_TIME_SLA || latency > MAX_LATENCY_SLA) {
slaViolations++;
}
}
}

// Calculate energy consumption
calculateEnergyConsumption();

// Calculate cost
calculateCost();

// Calculate bandwidth (average)
calculateBandwidth();
}

private static void calculateEnergyConsumption() {
totalEnergy = 0.0;
for (ContainerHost host : hostList) {
if (host instanceof PowerContainerHost) {
PowerContainerHost powerHost = (PowerContainerHost) host;
totalEnergy += powerHost.getPower();
}
}
}

private static void calculateCost() {
totalCost = 0.0;

// VM cost calculation
for (ContainerVm vm : vmList) {
if (vm.getHost() != null) {
double vmRuntime = makespan; // Simplified - using makespan as runtime
double vmCost = vmRuntime * 0.05; // $0.05 per second
totalCost += vmCost;
}
}

// Storage cost
double storageCost = makespan * 0.001; // $0.001 per second
totalCost += storageCost;

// Bandwidth cost
double bandwidthCost = totalBandwidth * 0.0001; // $0.0001 per MB
totalCost += bandwidthCost;

// Energy cost (assuming $0.15 per kWh)
double energyCostKWh = totalEnergy / 3600000.0; // Convert joules to kWh
totalCost += energyCostKWh * 0.15;

// SLA violation penalties
double slaPenalty = slaViolations * 10.0; // $10 per violation
totalCost += slaPenalty;
}

private static void calculateBandwidth() {
totalBandwidth = 0.0;
for (ContainerCloudlet cloudlet : cloudletList) {
if (cloudlet.getCloudletStatus() == Cloudlet.SUCCESS) {
// Estimate bandwidth usage based on cloudlet characteristics
double bandwidthUsage = cloudlet.getCloudletFileSize() + cloudlet.getCloudletOutputSize();
totalBandwidth += bandwidthUsage;
}
}
}

private static void printComprehensiveMetrics() {
DecimalFormat df = new DecimalFormat("###.##");

// Cost breakdown
Log.printLine("\n--- Cost Breakdown ---");
Log.printLine("VM Compute Cost: $" + df.format(totalCost * 0.6)); // Estimated
Log.printLine("Storage Cost: $" + df.format(totalCost * 0.1)); // Estimated
Log.printLine("Bandwidth Cost: $" + df.format(totalCost * 0.05)); // Estimated
Log.printLine("Energy Cost: $" + df.format(totalCost * 0.2)); // Estimated
Log.printLine("SLA Penalties: $" + df.format(totalCost * 0.05)); // Estimated
Log.printLine("Total Cost: $" + df.format(totalCost));

// Efficiency metrics
double efficiency = (completedCloudlets * 100.0) / (totalCost + 1);
Log.printLine("Cost Efficiency: " + df.format(efficiency) + " cloudlets/$");

}

private static String getExperimentName(String... args) {
StringBuilder experimentName = new StringBuilder();
for (int i = 0; i < args.length; ++i) {
if (!args[i].isEmpty()) {
if (i != 0) {
experimentName.append("_");
}
experimentName.append(args[i]);
}
}
return experimentName.toString();
}

private static ContainerDatacenterBroker createBroker(int overBookingFactor) {
ContainerDatacenterBroker broker = null;
try {
broker = new ContainerDatacenterBroker("Broker", overBookingFactor);
} catch (Exception e) {
e.printStackTrace();
return null;
}
return broker;
}

private static List createHostList(int hostsNumber) {
ArrayList hostList = new ArrayList();
for (int i = 0; i < hostsNumber; ++i) {
int hostType = i % 3; // Distribute host types evenly
ArrayList peList = new ArrayList();
for (int j = 0; j < ConstantsExamples.HOST_PES[hostType]; ++j) {
peList.add(new ContainerVmPe(j,
new ContainerVmPeProvisionerSimple((double) ConstantsExamples.HOST_MIPS[hostType])));
}

hostList.add(new PowerContainerHostUtilizationHistory(
IDs.pollId(ContainerHost.class),
new ContainerVmRamProvisionerSimple(ConstantsExamples.HOST_RAM[hostType]),
new ContainerVmBwProvisionerSimple(1000000L),
1000000L, peList,
new ContainerVmSchedulerTimeSharedOverSubscription(peList),
ConstantsExamples.HOST_POWER[hostType]));
}
return hostList;
}

public static ContainerDatacenter createDatacenter(
String name, Class< extends ContainerDatacenter> datacenterClass,
List hostList,
ContainerVmAllocationPolicy vmAllocationPolicy,
ContainerAllocationPolicy containerAllocationPolicy,
String experimentName, double schedulingInterval, String logAddress,
double VMStartupDelay, double ContainerStartupDelay) throws Exception {

String arch = "x86";
String os = "Linux";
String vmm = "Xen";
double time_zone = 10.0;
double cost = 3.0;
double costPerMem = 0.05;
double costPerStorage = 0.001;
double costPerBw = 0.0;

ContainerDatacenterCharacteristics characteristics = new ContainerDatacenterCharacteristics(
arch, os, vmm, hostList, time_zone, cost, costPerMem,
costPerStorage, costPerBw);

ContainerDatacenter datacenter = new PowerContainerDatacenterCM(
name, characteristics, vmAllocationPolicy,
containerAllocationPolicy, new LinkedList(),
schedulingInterval, experimentName, logAddress,
VMStartupDelay, ContainerStartupDelay);

return datacenter;
}

private static ArrayList createVmList(int brokerId, int containerVmsNumber) {
ArrayList containerVms = new ArrayList();

for (int i = 0; i < containerVmsNumber; ++i) {
ArrayList peList = new ArrayList();
int vmType = i % 4; // Distribute VM types evenly

for (int j = 0; j < ConstantsExamples.VM_PES[vmType]; ++j) {
peList.add(new ContainerPe(j,
new ContainerPeProvisionerSimple((double) ConstantsExamples.VM_MIPS[vmType])));
}

containerVms.add(new PowerContainerVm(
IDs.pollId(ContainerVm.class), brokerId,
(double) ConstantsExamples.VM_MIPS[vmType],
(float) ConstantsExamples.VM_RAM[vmType],
ConstantsExamples.VM_BW, ConstantsExamples.VM_SIZE, "Xen",
new ContainerSchedulerTimeSharedOverSubscription(peList),
new ContainerRamProvisionerSimple(ConstantsExamples.VM_RAM[vmType]),
new ContainerBwProvisionerSimple(ConstantsExamples.VM_BW),
peList, ConstantsExamples.SCHEDULING_INTERVAL));
}

return containerVms;
}

private static List createContainerList(int brokerId, int containersNumber) {
ArrayList containers = new ArrayList();

for (int i = 0; i < containersNumber; ++i) {
int containerType = i % 3; // Distribute container types evenly

containers.add(new PowerContainer(
IDs.pollId(Container.class), brokerId,
(double) ConstantsExamples.CONTAINER_MIPS[containerType],
ConstantsExamples.CONTAINER_PES[containerType],
ConstantsExamples.CONTAINER_RAM[containerType],
ConstantsExamples.CONTAINER_BW, 0L, "Xen",
new ContainerCloudletSchedulerDynamicWorkload(
ConstantsExamples.CONTAINER_MIPS[containerType],
ConstantsExamples.CONTAINER_PES[containerType]),
ConstantsExamples.SCHEDULING_INTERVAL));
}

return containers;
}

private static List createContainerCloudletList(int brokerId, int numberOfCloudlets)
throws FileNotFoundException {

String inputFolderName = "/home/soft13/soft13/Project 2019/Cloudsim-4.0-examples/src/workload/planetlab";
ArrayList cloudletList = new ArrayList();
long fileSize = 300L;
long outputSize = 300L;
UtilizationModelNull utilizationModelNull = new UtilizationModelNull();

java.io.File inputFolder1 = new java.io.File(inputFolderName);
java.io.File[] files1 = inputFolder1.listFiles();
int createdCloudlets = 0;

for (java.io.File aFiles1 : files1) {
java.io.File inputFolder = new java.io.File(aFiles1.toString());
java.io.File[] files = inputFolder.listFiles();

for (int i = 0; i < files.length; ++i) {
if (createdCloudlets < numberOfCloudlets) {
ContainerCloudlet cloudlet = null;

try {
cloudlet = new ContainerCloudlet(
IDs.pollId(ContainerCloudlet.class),
ConstantsExamples.CLOUDLET_LENGTH, 1,
fileSize, outputSize,
new UtilizationModelPlanetLabInMemoryExtended(
files[i].getAbsolutePath(), 300.0D),
utilizationModelNull, utilizationModelNull);
} catch (Exception e) {
e.printStackTrace();
System.exit(0);
}

cloudlet.setUserId(brokerId);
cloudletList.add(cloudlet);
createdCloudlets += 1;
} else {
return cloudletList;
}
}
}
return cloudletList;
}

private static void printCloudletList(List list) {
int size = list.size();
ContainerCloudlet cloudlet;

String indent = " ";
Log.printLine();
Log.printLine("========== CLOUDLET EXECUTION DETAILS ==========");
Log.printLine("Cloudlet ID" + indent + "Container ID" + indent + "STATUS" + indent
+ "Data center ID" + indent + "VM ID" + indent + "Time" + indent
+ "Start Time" + indent + "Finish Time");

DecimalFormat dft = new DecimalFormat("###.##");
for (int i = 0; i < size; i++) {
cloudlet = list.get(i);
Log.print(indent + cloudlet.getCloudletId() + indent);
Log.print(cloudlet.getContainerId() + indent);

if (cloudlet.getCloudletStatusString().equals("Success")) {
Log.print("SUCCESS");

Log.printLine(indent + indent + cloudlet.getResourceId()
+ indent + indent + indent + cloudlet.getVmId()
+ indent + indent
+ dft.format(cloudlet.getActualCPUTime()) + indent
+ indent + dft.format(cloudlet.getExecStartTime())
+ indent + indent
+ dft.format(cloudlet.getFinishTime()));
}
}
}
}

Screenshots

List

Office Address

Social List

How to Perform Comprehensive Cost Analysis—Including Compute, Storage, Bandwidth, Energy, and SLA Penalties—in a Simulated Cloud Environment?

Condition for Perform Comprehensive Cost Analysis—Including Compute, Storage, Bandwidth, Energy, and SLA Penalties—in a Simulated Cloud Environment

Sample Code

Screenshots

S-Logix (OPC) Private Limited
