Polygon Based Topology Formation and Information Gathering in Satellite Based Wireless Sensor Network - 2020

Polygon Based Topology Formation and Information Gathering in Satellite Based Wireless Sensor Network

Research Area:  Wireless Sensor Networks


The satellite network is one of the major source of information and these days small satellites are gaining lot of focus. The group of small satellites form a distributed network that work collaboratively to accomplish the mission task. These networks are very similar to the terrestrial wireless sensor network in terms of restricted resources and constrained capabilities. Sometimes, network of small satellites is also called as space based wireless sensor network (SBWSN). In any distributed network, topology formation and its control plays a significant role. This is true for SBWSN also. The topology in SBWSN decides the area of coverage (field of view), time of coverage, data gathered and data transmitted to ground station. The proposed topology is a distributed network of small satellites formed by trivalent, toroidal and spherical polyhedron graph forming a fullerene, which is called as polygon based network topology (PBNT). It comprises of both pentagonal (Fp) and hexagonal (Fh) faces with K regular graphs such that K ≥ 3 with genus equal to 1. It also satisfies Eulers formula with n vertices. The fullerene comprises of simple rings and each of this ring forms the cluster. Each cluster is further represented as a triangular grid, that is linearly convex or non-linear, with K-connected graph along with Hamiltonian extendible cycle. The nodes/satellites on the triangular grid represent sensing nodes (low capability nodes/satellites), while the vertices of the ring are sink nodes (higher capability nodes/satellites). In this work, the topology is formed by small satellites (pico or nano satellites). In the proposed topology formation, the network is considered as virtual network with logical neighbours forming the cluster. Each node in the cluster covers a particular swath for a particular time interval based on the mission payload and on the p3 tiling. In the simulation, we consider n small satellites being placed in low earth orbit (LEO), (where n ranges from 3 to 150). The performance enhancements are seen during simulation in the following parameters, (1) Coverage Area: The coverage area increases as multiple satellites have different field of view at different times. (2) Reduces Gaps:The proposed distributed network also minimises uncovered areas as multiple satellites cover the target location at different time stamp which is not possible by a single large satellite. (3) Increase in Data Throughput: Each satellite in the network transmits data, when it is at perigee. The data throughput of the network increases, as data is transmitted by multiple satellites. Therefore, the throughput is increased by n-fold. (4) Continuous Connectivity: The data captured by one satellite in the network is made available to other using multi-hop communication. Thus the proposed topology also increases the continuous connectivity between satellites and also with the ground station. (5) Increases lifetime and Network Reliability: The SBWSN accomplishes its mission task even when one/more satellites encounters functional failure. The satellites in the network can reconfigure themselves and continue the mission task. Thus SBWSN also reduces the risk of mission failure and ensures mission reliability. Due to reconfiguration the lifetime of the network is also increased. The proposed topology is used for small satellites (specially nano and pico satellites) network, which permit the single board satellite weighing less than 10 kg (Pico satellite less than 1 kg and nano satellites less than 10 kg). The advantage of these small satellites network over single large satellite is low cost and reduced development time, as it uses commercially of the shelf (COTS) components. In this paper, we propose network architecture formed by the spherically embedded clusters formed by polyhedron. The vertices of polyhedron have both pentagonal (Fp) and hexagonal (Fh) faces with K regular graphs such that K ≥ 3, with genus equal to 1. The vertices of these polyhedron form the sink nodes and the other nodes are sensing nodes. Here satellites and nodes are interchangeably used. Sensing nodes are used for data gathering (pico/nano), while sink nodes are higher capability nodes which perform computational extensive operations in the network (nano or macro satellites). The sensing and sink nodes transmit data to the ground station when they are at perigee. The main objective of the proposed work is, technology demonstration of low cost, distributed small satellites network for earth observations replacing single huge satellite.


Author(s) Name:  Padmaja Kuruba,N. D. Dushyantha

Journal name:  Wireless Personal Communications

Conferrence name:

Publisher name:  Springer

DOI:  10.1007/s11277-020-07568-9

Volume Information:  volume 115, pages 203–237 (2020)
