How to Create an Amazon EMR Cluster with Spark and Hive

Goal: Launch EMR with Spark + Hive
Description:
This workflow guides through to creating an Amazon EMR cluster with Spark and Hive using the AWS Management Console. You begin by selecting EMR on EC2 and defining the cluster name, applications, and operating system. Next, you configure the cluster using uniform instance groups and set up the node types, including one master and two core nodes. After choosing manual scaling, you configure networking using default VPC settings and enable log storage in an S3 bucket. You then specify security settings, select an EC2 key pair, and create the required IAM roles for the EMR service and EC2 instances. Finally, you review the configuration and launch the cluster, resulting in a fully provisioned EMR environment ready for big data processing.

Go to AWS → EMR → Create Cluster
Choose Release 6.x
Select:
   Hadoop
   Spark
   Hive
Set:
   1 Master, 2 Core nodes
   EC2 key pair
   Logging → S3 bucket
Launch cluster
Result: EMR cluster ready
Step 1: Open EMR
Go to AWS Console → Services
Search → EMR
Click EMR on EC2
Click Create cluster

Step 2: Name and Applications

Setting	Select / Enter
Name	My-EMR-Spark-Hive-Cluster (or any name)
Application Bundle	Custom
Select Applications	✅ Hadoop ✅ Hive ✅ Spark (Others can remain, but ensure these 3 are selected)
AWS Glue Data Catalog (optional)	You can leave unchecked for now
Operating System	✅ Amazon Linux (default)

Step 3: Cluster Configuration

Option	Select
Cluster configuration method	Uniform instance groups

Step 4: Node Configuration

Node Type	Instance Type	Count
Primary (Master)	m5.xlarge (or r8g.xlarge if available in your region)	1
Core	m5.xlarge	2
Task	Leave empty (not required for now)	—

Leave Use high availability unchecked
Leave EBS volume as default (15–100 GiB is fine)

Step 5: Cluster Scaling
Choose: Set cluster size manually
Then Verify :

Group	Instance Type	Instance Count
Core	m5.xlarge	2
Task	Not needed	0

Step 6: Networking

Setting	Select
VPC	Default VPC (or your VPC)
Subnet	Any public subnet
Security Group	Default (EMR will auto-create security groups if needed)

Step 7: Cluster Logs
Enable logging and choose/create an S3 bucket
Example: s3://my-emr-cluster-logs/

Step 8: Security & Key Pair

Setting	Choose
Security configuration	Leave default
EC2 Key Pair	✅ Select your SSH key (or create new)

Step 9: IAM Role
Create EMR Service Role
Step 1: Open IAM
Go to AWS Console
Search IAM → Open it
Click Roles (left menu)
Click Create role
Step 2: Select trusted entity
Choose: AWS Service
Use case: EMR
Then select: EMR – Elastic MapReduce
Click Next
Step 3: Attach Policies (required)
Add these 2 policies:
   AmazonEMRServicePolicy
   AmazonEC2FullAccess (or leave default EMR-recommended policies if shown)
Click Next
Step 4: Name the role
Role name: EMR_DefaultRole
Click Create role
Done – Service role created
Create EC2 Instance Profile Role (for EMR nodes)
Step 1: Create new role
In IAM → Roles
Click Create role
Step 2: Select trusted entity
Choose: AWS Service
Use case: EC2
Click Next
Step 3: Attach Policies
Add these policies:
   AmazonElasticMapReduceforEC2Role
   AmazonS3FullAccess (or a restricted bucket access policy)
Click Next
Step 4: Name the role
Role name: EMR_EC2_DefaultRole
Click Create role
Done – Instance role created
Step 10: Create Cluster
Click Create cluster → EMR cluster ready
